YubiKey setup

PIV

Windows

Prerequisites:

• Install OpenSC Library for PKCS11 (Documentation)
• Install Yubikey Manager CLI
• Yubico Authenticator
• Have your PIN and Management Key ready (store in Vaultwarden)
• Make sure, OpenSC ignores Windows Hello (see Troubleshooting below)
• Make sure, you use supported algorithms (see Troubleshooting below)

---

1. Generate a keypair (select one of the working algos: prefer eccp384 over rsa3072 over rsa2048):

ykman piv keys generate --touch-policy never --pin-policy once -a eccp384 9a pubkey.pem

2. Create a self signed cert based on this key:

ykman piv certificates generate 9a pubkey.pem --subject "CN=SSH Key" --valid-days 36500

3. Retrieve your public key and add to ~/.ssh/authorized_keys on the remote host:

ssh-keygen -D "C:\Program Files\OpenSC Project\OpenSC\pkcs11\opensc-pkcs11.dll"

4. Connect with ssh:

ssh -I "C:\Program Files\OpenSC Project\OpenSC\pkcs11\opensc-pkcs11.dll" user@IP

5. (Recommended) Add to your ~\.ssh\config (create file if it doesn't exist):

PKCS11Provider "C:\Program Files\Yubico\Yubico PIV Tool\bin\libykcs11.dll"

Troubleshooting

---

Windows Hello

It is possible that OpenSC recognizes "Windows Hello" as its own device, thus you extract its RSA key. To prevent this, modify C:\Program Files\OpenSC Project\OpenSC\opensc.conf to:

app default {
	# debug = 3;
	# debug_file = opensc-debug.txt;
	ignored_readers = "Windows Hello" ; # Ignore all readers containing "Windows Hello"
}

To list all devices, run & "C:\Program Files\OpenSC Project\OpenSC\tools\opensc-tool.exe" --list-readers (PowerShell).

Error: signing failed for RSA "PRIV AUTH pubkey: error in libcrypto"

Don't forget to youch your key, when authenticating 😉. It may be possible that you use unsupported algos, such as:

• rsa4096
• ed25519
• x25519 (failed on certificate creation)

Known working algos are:

• rsa1024 (probably, pls. don't use)
• rsa2048 (default)
• rsa3072
• eccp384 (sign-only, no de/encryption, prefer this for ssh)

Agent forwarding

You can forward the YubiKey's authentication capabilities to the remote server, so that you can use this server as a jump host to another remote destination.
A classic example is developing on a remote machine and using SSH to push the changes to GitLab.

You must set your pin-policy to once (not always). You cannot change this setting after key creation (you must create new keys).

To enable agent forwarding you must load your SSH the key into your agent using:

ssh-add -s "C:\Program Files\Yubico\Yubico PIV Tool\bin\libykcs11.dll"

You can check if this was successfull using ssh-add -L and, if necessary, clear the key using ssh-add -D.

Your client must know to which remote hosts it should forward the agent. Use ssh -A user@ip to forward the agent.
You can optionally add ForwardAgent yes to your ~\.ssh\config, e.g.:

Host alias1 alias2
    HostName HostOrIp
    PKCS11Provider "C:\Program Files\OpenSC Project\OpenSC\pkcs11\opensc-pkcs11.dll"
    User username
    ForwardAgent yes

WARNING

Don't forward the agent to all destinations. Only to destinations where needed.

Now the remote host also needs to accept your forwarded agent. Add AllowAgentForwarding yes to /etc/ssh/sshd_config on the remote host.
Reconnect and check if the agent was forwarded:

ssh-add -L
ssh-rsa AAAAB...

Your agent was forwarded successfully. You can now connect to other destinations from there. 🍵

Linux

TODO
See also: YubiKey SSH guide

GPG

Setup only.

sudo apt update
sudo apt install -y \
  gnupg2 \
  gnupg-agent \
  scdaemon \
  pcscd \
  pcsc-tools \
  yubikey-personalization


sudo systemctl enable --now pcscd

~/.gnupg/gpg-agent.conf
enable-ssh-support
default-cache-ttl 600
max-cache-ttl 7200
pinentry-program /usr/bin/pinentry-gnome3

gpgconf --kill gpg-agent

in .bashrc /.zshrc
export SSH_AUTH_SOCK=$(gpgconf --list-dirs agent-ssh-socket)

gpgconf --launch gpg-agent

Certificate creation: TODO
